LP Wholesale Fine Ultra-Thin Copper Winding Wire Price 0.02mm 0.01mm 0.09mm swg-16 super enameled copper wire

FOB Reference Price:Get Latest Price
US $8-11 / Kilogram | 300 Kilogram/Kilograms enameled round copper wire,enameled flat copper wire (Min. Order)
Supply Ability:
1500 Kilogram/Kilograms per Week Enameled Wire Copper Winding Wire And Price
Port:
Qingdao,Shanghai,Tianjin,Hongkong
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Henan, China (Mainland)
Brand Name:
LP Magnet Wire
Model Number:
Enameled Copper Wire
Type:
Insulated
Application:
Enameled Copper Wire for motor,transformer modern instrument, motor,transformer,modern instrument,Generator,welding machine
Conductor Material:
Copper
Conductor Type:
Solid
Insulation Material:
Enameled
Product name:
Wholesale Enameled Wire Ultra-Thin Copper Winding Wire And Price
Diameter:
round:0.025-4.5mm;flat: a:1-10,b:3-16;square :a(b) 0.4-7mm
Bobbin:
PT-4--PT-200
Insulation:
PEW, PIW, EIW, AIW, EI/AIW
Certification:
SGS,UL,ISO9001,ISO4001
Temperature class:
130,155,180,200,220
Standard:
IEC,NEMA,GB,JIS
Feature:
high strength, high temperature, solvent resistance,
Enamel:
ELANTAS
Packaging & Delivery
Packaging Details
Wholesale Enameled Wire Ultra-Thin Copper Winding Wire And Price
Standard packaging :PT-4--PT-200 Different size bobbin with export carton or wooden box on pallet or as customer requirement.
Delivery Time
Shipped in 7 days after payment

LP Wholesale Enameled Wire Ultra-Fine Copper Winding Wire And Price 0.02mm

Product Description

Products & Standard

TypeProduct NameStandard
Q(Z/ZY)/180Polyester-imide Coated Polyester Efficient Motor Special Enamelled Copper Round WireQ/HYT1801-2012
QZY/180(EIW180)Polyester-imide Enameled Round Copper Wire,Class180

GB/T6109.5-2008

IEC60317-8:1997

QZ/130L,QZ/155(PEW130,PEW155)Polyester Enameled Round Copper Wire,Class 130,155

GB/T6109.22008

IEC60317-3:2004

 1. Characteristic of enamel winding copper wires

(1)Good performace at softening breakdown
(2)Suitable for high-speed automated routing
(3)Able to be direct weld, with no pinhole
(4)Resistive to high frequency, wearing, refrigerants and electronics corona
(5)High breakdown voltage, small dielectric loss angle



Enameled copper wire has a surface coating of high strength, high temperature, solvent resistance, good flexibility, small size, low full tank, suitable for manual and automatic mechanical winding, embedded line.



Such as :QZY-2/180 Diameter:1.000mm

Performance

International standard

Factory Standard

Breakdown Voltage

>=5.0kv

8.0±0.5kv

Conductor Diameter

±0.010mm

0.998±0.005mm

Spring-Back Angle

<=45°

35±2°

Elongation

>=30%

>=36%

Cut-Through Resistance

<=0.017241Ω.mm2/m

0.01700-0.01710Ω.mm2/m



Production Flow

Our products are subject to stringent production processes, to ensure Wholesale Enameled Wire Ultra-Thin Copper Winding Wire And Price quality from every detail



Packaging & Shipping



Our products will be made the most inner plastic packaging.Then the product will be packed in cartons and wooden cases as double protection in order to protect the Wholesale Enameled Wire Ultra-Thin Copper Winding Wire And Price from wear and tear duringtransport.



Product Packaging

Diameter(m)

Bobbin

Capacity

1.000-1.560

PT200

4 Spool/800kg

0.510-0.960

PT90

4 Spool/810kg

0.310-0.500

PT25

50 Spool/1250kg



Certifications

Our company has complete certification system.Including ISO9001,ISO14001,ROHS,SGS and UL certification.Our products have been exported to more than 50 countries around the world.



Company Information

Founded in 1993, Zhengzhou LP Industry Co., Ltd is a professional magnet wire manufacturer in China who uphold the concept of “quality first ”; our products export to more than 50 countries and regions including Europe ,the US,Asia and Africa and so on and we are cooperating with over 200 oversea customers.


All the products adopts IEC, GB, JIS, NEMA standard, and are widely used in the manufacture of motor, transformer, power, electric welding, instrument and meter, household appliances, refrigeration compressor, deflecting coil, special motor, high-frequency transformer and electronic, electrical products.





Our Services



Other Question:



◊ Brand new service team is ready to answer your questions

Timely delivery to reduce your waiting time

Perfect after-sales service

Looking forword a cooperation with you sincerely



FAQ

1.How long has your factory set up?

We started production in 1993.



2.how about your company's annual production capacity?

Our Company's annual production is about 8,000 tons.



3.How large the scale of your company?

Our Company covers almost 100,000 square meters, including plant area of 80,000 square meters.



4. What's your company 's product scope?

we have many kinds of products ,such as enameled aluminum wire, enameled cooper wire, paper covered magnet wire, fiber glass covered magnet wire and other aluminum/cooper magnet wire products.



5. Some parameters about your company products

Enameled copper wire(mm):Round 0.025-4.5 Flat a1-10,b3-16

Enameled aluminum wire(mm):Round 0.2-8.0 Flat a1-10,b3-16

Fiber glass covered wire(mm): Round 1-7 Flat a1-10,b3-35

Paper covered wire (mm):Round 2-7 Flat a1-10,b3-35

ECCA wire (mm):Round 0.19-4.0



6. Why choose us?

Guarantees of Coil winding wire :
1) Factory Direct and on-time shipment.
2) ELANTAS insulation paint available.
3) Large size safe package up to PT-270.
4) Customized sizes,OEM are accepted!
5) Goods are sold with rerun or refund guarantee due to quality issue!

Shipping terms of Coil winding wire

1) Sample time: Nearby 3-5days, distance 5-7days.
2) Production time: 10-30days(Depends on the Qty) after advanced payment received
3) Packing: Each into individual carton box, then into export carton
